General Specifications

• Type: A4 (up to 8.5" × 14") Monochrome Desktop Laser Printer

• Print speed:

  • Up to 21 ppm for typical documents (A4), 20 ppm A4 in some specs

• First-print time: ~8 seconds or less

• Warm-up time: 20 seconds or less

• Monthly duty cycle: Up to 8,000 pages

Printing & Resolution

• Resolution: 600 × 600 dpi native, up to Fast 1200 (interpolated)

Paper Handling

• Input: Single 150-sheet front tray (max. 150 sheets)

• Output: 50 sheets, face-down

• Supported paper sizes: A5 to Legal (8.5" × 14")

• Paper weight: 65–105 g/m² (bond 20–28 lb)

Interfaces & Connectivity

• Connectivity:

  • Standard USB 2.0 (Hi-Speed)

  • Wireless LAN on PA2000w model

• Mobile printing: Supports KYOCERA Mobile Print (iOS/Android), AirPrint, Mopria

Controller & Memory

• Engine Processor: STMicro STM32G071RBT6 (20 MHz)

• System Processor: ARM926EJ equivalent (~450 MHz)

  Memory: 32 MB (standard; same as maximum)

Power Consumption

• Printing: ~333.7 W (120 V) / ~330 W (220–240 V)

• Ready mode: ~2.3 W

• Sleep mode: ~0.4 W

• Max power usage: ~658 W (120 V) / ~700 W (220–240 V)

• Typical Energy Consumption (TEC): ~0.22 kWh/week

Environmental & Noise

• Noise level: Approx. 52 dB(A) when printing; 28 dB(A) in standby

• Additional modes: EcoPrint Mode (energy-saving), Quiet Mode (reduced noise)

Security & Utilities

• Security: WPA2-PSK (AES) for wireless encryption

• Supported protocols: TCP/IP, IPv4, LPR, Port9100, WSD (USB-only), DHCP, DNS

  Utilities: Web Installer, Wireless Setup Tool, Maintenance Menu, KYOCERA Client Tool, status monitor, driver support (GX, KPSL for Mac/Linux, TWAIN, WIA)

Consumables & Options

• Toner: TK-1242 (High Capacity Black Toner, ~1,500 pages—ISO 19752)

• Drum: DK-1242 (Black Drum, ~10,000 pages)

• Starter toner: ~700 pages yield

Physical Design & Weight

• Dimensions (W × D × H): 350 × 233 × 177 mm (~13.8″ × 9.2″ × 7.0″)

• Weight: ~4.5 kg (≈9.9 lb) with starter container
